360 Systems TSS-4000 Multi Format Video Server
Description
More channels for the same price* = lower cost per channel. For those customers requiring high playout channel counts, the TSS-4000 provides exceptional cost per channel. The TSS-4000 is a compact 1U server with up to 8TB of storage and offers 4 simultaneous HD or SD playout channels. With the same software and the core reliability of the TSS line of server, the TSS-4000 is the choice for broadcast quality playout.
*When compared to the TSS-3100
Video:
Playout in 720p, 1080i or SD on any channel
Various standard codec and file formats are accepted for playout, such as H.264 or MPEG-2 in .mxf, .mp4, .mpg or .mov containers.
Independently configure each output to broadcast in 720p, 1080i or SD
Perform jog and shuttle for rapid movement within a clip
Smooth slow motion playout
16 channels of embedded audio per video channel
Configurable for 29.97/59.94 or 25/50
High quality 10 bit video and 24 bit audio support
Reliability:
Redundant cooling and power
Redundant RAID 5 storage
Linux based operating system
Connectivity:
HD-SDI, SD-SDI compatibility
Gigabit Ethernet
Serial port control for each channel via the VDCP or Odetics protocols for use with automation or remote controls
Independent GPI inputs and outputs (12 each) for external triggering or control
Software:
Automatic conversion plays SD and HD files back-to-back
Local software GUI
Remote control from a PC
Simple playlisting
Key Features:
- 4 Playout Channels
- 16 Channels Embedded Audio
- H.264 and MPEG2 Encoding / Decoding
- Automatic Up/Down/Cross Conversion of HD or SD content
- Remote Control From PC’s via Ethernet
- Redundant Power / Cooling
- 1U Form Factor
