Fujinon XK6x20-SAF PL Mount 35mm Lens with Servo Grip

POA
Stock Code:
148011
Enquire for ETA

Description

XK6x20 is a zoom lens for cinema camera that offers high optical performance compatible with 4K cameras and covers a wide range of focal length from 20mm to 120mm. It also realizes T3.5 brightness in the entire zoom range. There is no T drop and it offers comfortable operation. Various scenes can be shot with this single lens.

“XK6x20” is equipped with detachable drive unit for electric zooming and focusing which is popular function with existing products. It also features 0.8M gear pitch for compatibility with standard accessories.

Features:

• Outstanding 4K optical performance and compact design
• Wide focal length from 20mm to 120mm
• T3.5 brightness in the entire zoom range
• 0.8M gear pitch
• Moderate focus torque with 200-degree rotation angle to aid accurate focusing
• Focus indicator can be displayed in feet or meters

Specifications:

Model name - XK6x20
Camera specifications - Super 35mm PL Mount camera
Focal length - 20mm - 120mm
Zoom ratio - 6x
T-no. - 3.5
Minimum object distance (M.O.D) - 1.1m/3.61ft
Object dimensions (at the M.O.D) - 20mm 1109mm × 624mm
[Horizontal × Vertical] - 120mm 182mm × 102mm
Angle of view [Horizontal × Vertical] - 20mm 63°41' × 38°30'
16:9 aspect ratio - 120mm 11°49' × 6°40'
Approx. size (f × Length) - f114mm x 239mm
Approx. Weight - 2.9kg (with drive unit) / approx. 2.4kg (without drive unit)
