Millennia HV-316/8 8 Channel Remote Dante Network Mic Preamp
Description
Remote-control-only 8-channel HV-3 in 1U rack chassis. Dante 192kHz Output. Designed for all professional environments. Ethernet control with PC or MAC software interface (included). DB-25 mic inputs. Analog Output option. MIDI control for plug and play compatibility.
The Millennia HV-316/8 is a cutting-edge 8-channel remote-control Ethernet mic preamp designed for adverse environments and mission-critical applications. It's perfect for live touring rigs, multi-room studio complexes. scoring stages, remote recording trucks, sample houses, hot-rack installs, schools, churches, networked music venues, location recording and outdoor facilities.The HV-316/8’s road-ready, lightweight military-spec aluminum 1U chassis houses eight channels of legendary Millennia HV-3 mic preamps with simultaneous analog and Dante 32-bit/192kHz Ethernet outputs.
Key Features:
- 8 channels of pristine Millennia HV-3 microphone preamplifiers in a road-hardened 1U chassis
- Effortless, vividly realistic, dynamically uniform HV-3 musical performance
- Dante network output standard -- analog output option.
- Both 12VDC (battery) and 80-264VAC worldwide powering
- Redundant power supply for fail-safe, glitch-free operation
- Paralleled next-generation AKM A-to-D conversion
- Designed for ultra-high-temperature continuous operation (65C / 150F)
- RF “pi filter” shielding provided on analog and digital feeds, destroys mobile interference
- Control up to 256 channels at once via conventional Ethernet
- +34dBu input headroom for use in the most extreme audio environments
- Matched discrete-octet transistor gain topology, the classic Millennia HV-3 double-balanced circuit
- Ælogic Mac & Windows third-generation software offers total control for both HV-316 and HV-3R on the same network
- High-definition meters, grouping, linking, scene management, temperature monitoring
- Entirely balanced audio path with precision components maintains signal integrity: THD under 10 PPM (< .001%)
- Laser-trimmed FET-based output stage (analog output option) drives 1000-foot (300m) cable runs with ease
- All channels matched to 0.08 dB
- Advanced power supply rated for 650,000 hours MTBF operation
- Aluminum 16-gauge rack chassis, ultra-lightweight, just 4.5kg
- Billet aluminum laser etched front-panel
- Lovingly hand-built and quality-assured in Northern California USA
Designed for adverse environments and mission-critical applications:
Extensive RF shielding is provided on audio and digital feeds to eliminate the possibility of cellular interference. Designed to withstand continuous operating temperatures up to 150°F, the HV-316/8 can be powered by both 12VDC and worldwide 90–240V AC with fail-safe operation.
Acclaimed Millennia remote preamps:
Millennia remote preamps can seamlessly operate on a single Ethernet network — up to 384 redundant audio channels — letting you remotely control Gain, Polarity, Pad, Mute, channel Linking, HPF, and selectable ribbon or phantom paths on every channel. You also have unlimited scene recall scripting and virtual scribble strips.
Next-gen 192kHz A/D conversion:
The HV-316/8 uses eight channels of meticulously integrated, next-generation AKM 192kHz A/D converters, multi-paralleled for extreme dynamic range performance and acclaimed Millennia sonics. All internal processing is achieved via a generic plug-and-play Linux Beagle processor to ensure non-obsolescence and easy field replacement. To say that engineers at Sweetwater are impressed with the Millennia HV-316/8 would be an understatement. With its bulletproof build, audiophile sonics, and innovative remote control capabilities, it’s a stunning technological achievement.
Options:
- Analog Output
- HV-316-8 Short-loaded 8 ch version can be upgraded to 16 ch at the factory
View the PDF for more information and specifications
